- Innovative, and compact LED effect.
- Very easy “plug & play” design: no experience needed!
- Standalone: sound activated with internal mic
- Master/slave: several units can be linked together for synchronized shows.
- Excellent built-in programs for wonderful, ever changing, light shows
- Based on 120 power LEDs (R=20 + G=20 + B=20 + O=20 + W=40):
- Extremely brilliant colors compared to effects with halogen lamps
- More dynamic effects compared to effects based on halogen lamps
- Very sharp white, blue, red and green laser-like beams
- No lamp replacements!
- Uses LEDs with extremely long lifespan!
- Virtually no heat production
- Very low power consumption
- Lightweight (no lamp transformers needed)
- Ultra fast strobe function
- Equipped with big optical lens for maximum light output and wide beam angle
- Perfect for small applications: discos, clubs, mobile DJs, home, …
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | dia 24 x 23 cm |
|---|---|
| General : Weight (kg) | 1.39 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Energy Label | No |
| General : Power consumption W | 13 |
| General : Color | black |
| General : Display | none |
| General : Fixation | optional standard clamp |
| General : IP rating | indoor |
| Control : Protocol | N/A |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | N/A |
| Light : lamp socket | none |
| Light : lamp | LED |
| Light : colors | Red, Green, Blue, White |
| Light : mix colors | No |
| Light : max. refresh rate (kHz) | No |
| Brand | JB SYSTEMS |
| EANCode | 5420025641661 |
