Details
Details
- A remarkably small and super lightweight moving wash!
- 4 powerful 12W, 6in1 RGBWAUV leds.
- The perfect solution for many applications: DJ’s, parties, pubs, ...
- Very low power consumption, only 60 W !
- A real lightweight: only 1,61kg !
- 0-100% dimming and different strobe effects.
- Excellent built-in programs for wonderful light shows.
- Multiple working modes:
- DMX-control: via 5, 9 or 15 channels
- Standalone: sound activated with internal mic
- Master/slave: wonderful synchronized lightshows.
- 4-digit LED-display for easy menu navigation.
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 13.9 x 18.3 x 14.3 |
|---|---|
| General : Weight (kg) | 1.61 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Energy Label | No |
| General : Power consumption W | 60 |
| General : Color | black |
| General : Display | LED |
| General : Fixation | included omega bracket |
| General : IP rating | indoor |
| Control : Modes | standalone sound, standalone automatic, remote, manual, DMX, Master/Slave |
| Control : Protocol | DMX |
| Control : Type included remote | IR Remote Control |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | 5 |
| Control : maximum DMX channels | 15 |
| Light : lamp socket | No |
| Light : Lux | 212 lux @ 5m |
| Light : lumen | 789 |
| Light : lamp | LED |
| Light : colors | UV, Amber, RGBWA+UV |
| Light : mix colors | No |
| Light : min. beam angle (°) | 25 |
| Light : max. beam angle (°) | 25 |
| Light : max. refresh rate (kHz) | No |
| Connections : input | 3 pin XLR, IEC |
| Connections : output | 3 pin XLR |
| Brand | JB SYSTEMS |
| EANCode | 5420025655309 |
Manual & Downloads
Manual & Downloads
 CLUBWASH MINI - Manual EN Size: (1.51 MB) |
CLUBWASH MINI - Manual English |
| CLUBWASH MINI - Manual NL Size: (1.58 MB) |
CLUBWASH MINI - Manual Nederlands |
| CLUBWASH MINI - Manual FR Size: (1.57 MB) |
CLUBWASH MINI - Manual Français |
| CLUBWASH MINI - Manual DE Size: (1.54 MB) |
CLUBWASH MINI - Manual Deutsch |
| CLUBWASH MINI - Manual ES Size: (1.53 MB) |
CLUBWASH MINI - Manual Español |
| CLUBWASH MINI - EC Declaration Size: (449.67 KB) |
CLUBWASH MINI - EC Declaration of Conformity |
| CLUBWASH_MINI PDF leaflet Deutsch Size: (1.27 MB) |
PDF_LEAFLET_CLUBWASH_MINI_B05530_de.pdf |
| CLUBWASH_MINI PDF leaflet English Size: (1.27 MB) |
PDF_LEAFLET_CLUBWASH_MINI_B05530_en.pdf |
| CLUBWASH_MINI PDF leaflet Français Size: (1.27 MB) |
PDF_LEAFLET_CLUBWASH_MINI_B05530_fr.pdf |
| CLUBWASH_MINI PDF leaflet Nederlands Size: (1.27 MB) |
PDF_LEAFLET_CLUBWASH_MINI_B05530_nl.pdf |
