- Just buy one effect and you have it all!
- This incredible effect mixes 3 different effects in wonderful combination:
- LED effect, similar to our LED DEVIL (5pcs 3watt leds with different colors: red, green, blue, orange, white)
- LED STROBE: powerful white LEDs (8pcs 1watt)
- LASER effect: wonderful red (150mW) / green (50mW) laser patterns, Class 3R laser.
- A lot of different internal programs to make life simple!
- DMX-control: 1channel for easy operation or 9 channels for full control.
- Standalone: sound activated (internal mic) or automatic.
- Master/slave: wonderful synchronized shows.
- 3-digit LED display for easy menu navigation
- IEC mains input + output for easy linking
- Key activated on/off switch and emergency switch (interlock) input for additional safety
- Complies to EN/IEC 60825-1 2007 for Laser Safety
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 24 x 22 x11 cm |
|---|---|
| General : Weight (kg) | 3.75 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Energy Label | No |
| General : Power consumption W | 66 |
| General : Color | black |
| General : Display | LED |
| General : Fixation | optional standard clamp |
| General : IP rating | indoor |
| Control : Modes | standalone sound, standalone automatic, DMX, Master/Slave |
| Control : Protocol | DMX |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | 1 |
| Control : maximum DMX channels | 9 |
| Light : lamp socket | No |
| Light : lamp | LED |
| Light : colors | Red, Green, Blue, White |
| Light : mix colors | No |
| Light : max. refresh rate (kHz) | No |
| Connections : input | 3 pin XLR, IEC |
| Connections : output | 3 pin XLR, IEC |
| Brand | JB SYSTEMS |
| EANCode | 5420025641760 |
