- A compact but powerful multi-beam LED-effect!
- Each of the 6 lenses contains a powerful 3Watt RGB LED.
- Thanks to perfect color mixing the six beams can have any color you like!
- Each 9° beam can be controlled individually to create an endless combination of customized effects.
- Excellent built-in programs for wonderful, ever-changing, light shows:
- Standalone: sound activated with internal mic
- Master/slave: wonderful synchronized shows
- SMART-DMX (previously known as DMX-MSL mode): thanks to this revolutionary new feature several LED Rainbow units, working in master/slave, can still be controlled by DMX! Even while connected in a DMX chain! (optional mini DMX splitter required)
- DMX: 22 channels for full control or easy control using only 1 or 7 channels.
- 2 optional remote controllers available:
- CA-8: wired remote for improved master/slave control
- RF-8 Set: wireless RF-remote for improved master/slave control
- Uses six powerful 3Watt RGB LEDs:
- Extremely brilliant beams compared to effects with halogen lamps
- More dynamic effects compared to effects based on halogen lamps
- No lamp replacements and very low power consumption
- Mains IEC in/outputs for easy linking using optional IEC cables
- Perfect for different applications: discos, clubs, mobile DJs, stage, ...
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 42.4 x 25.1 x 6.5 cm |
|---|---|
| General : Weight (kg) | 3.44 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Works on battery | N/A |
| General : Energy Label | No |
| General : Power consumption W | 39 |
| General : Color | black |
| General : Display | none |
| General : Fixation | optional standard clamp |
| General : IP rating | indoor |
| Control : Protocol | N/A |
| Control : optional remote | CA-8, RF8-SET |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | N/A |
| Control : maximum DMX channels | 22 |
| Light : lamp socket | none |
| Light : lamp | LED |
| Light : colors | Red, Green, Blue |
| Light : mix colors | No |
| Light : min. beam angle (°) | 9 |
| Light : max. beam angle (°) | 9 |
| Light : max. refresh rate (kHz) | No |
| Brand | JB SYSTEMS |
| EANCode | 5420025641692 |
Manual & Downloads
Manual & Downloads
 LED RAINBOW Manual v1.05 Size: (3.09 MB) |
LED RAINBOW Manual v1.05 |
| LED RAINBOW EC declaration Size: (570.29 KB) |
LED RAINBOW EC declaration |
| LED_RAINBOW PDF leaflet Deutsch Size: (1.02 MB) |
PDF_LEAFLET_LED_RAINBOW_04169_de.pdf |
| LED_RAINBOW PDF leaflet English Size: (1.02 MB) |
PDF_LEAFLET_LED_RAINBOW_04169_en.pdf |
| LED_RAINBOW PDF leaflet Français Size: (1.02 MB) |
PDF_LEAFLET_LED_RAINBOW_04169_fr.pdf |
| LED_RAINBOW PDF leaflet Nederlands Size: (1.02 MB) |
PDF_LEAFLET_LED_RAINBOW_04169_nl.pdf |
