Details
Details
- The best of both worlds: a traditional 2 color laser + laser burst effects combined in one unit!
- Fabulous preprogrammed laser shows for all kinds of applications: lounge bar, discotheque, mobile DJ,...
- Class 3B laser based on 40mW 532nm green + 200mW 450nm blue laser.
- The color of the beams changes all the time using laser blanking technology.
- Several working modes:
- DMX-control: 1channel for easy operation or 10 channels for full control
- Standalone: sound activated (internal mic) or automatic
- Master/slave: wonderful synchronized shows
- Optional CA-8 remote controller available
- Compatible with RF-DMX Converter:
* Set the Radiant laser to 1CH DMX-mode
* Set the RF-DMX Converter to MODE1
- Built-in microphone
- 3-digit LED display for easy menu navigation
- Optional CA-8 controller for additional functions available
- Key actuated on/off switch and emergency switch (interlock) input for additional safety
- Complies to EN/IEC 60825-1 :2014 for Laser Safety
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 25 x 24 x 19 cm |
|---|---|
| General : Weight (kg) | 2.92 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Works on battery | N/A |
| General : Energy Label | No |
| General : Power consumption W | 30 |
| General : Color | black |
| General : Display | LED |
| General : Fixation | optional standard clamp |
| General : IP rating | indoor |
| Control : Protocol | N/A |
| Control : optional remote | CA-8, RF-DMX converter |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | N/A |
| Control : maximum DMX channels | 10 |
| Light : lamp socket | No |
| Light : lamp | None |
| Light : colors | Green, Blue |
| Light : mix colors | No |
| Light : max. refresh rate (kHz) | No |
| Connections : output | 3 pin XLR |
| Brand | JB SYSTEMS |
| EANCode | 5420025642224 |
Manual & Downloads
Manual & Downloads
 RADIANT LASER - Manual v1.20 EN Size: (1.19 MB) |
RADIANT LASER - Operation Manual v1.20 English |
| RADIANT LASER - Manual v1.20 FR Size: (2.04 MB) |
RADIANT LASER - Mode d'emploi v1.20 Français |
| RADIANT LASER - Manual v1.20 NL Size: (1.18 MB) |
RADIANT LASER - Handleiding v1.20 Nederlands |
| RADIANT LASER - Manual v1.20 DE Size: (1.96 MB) |
RADIANT LASER - Bedienungsanleitung v1.20 Deutsch |
| RADIANT LASER - Manual v1.20 ES Size: (2.53 MB) |
RADIANT LASER - Manual de instrucciones v1.20 Español |
 RADIANT LASER - Chromateq fixture files Size: (4.91 KB) |
RADIANT LASER - Chromateq fixture files |
| RADIANT_LASER PDF leaflet Deutsch Size: (1.49 MB) |
PDF_LEAFLET_RADIANT_LASER_B04222_de.pdf |
| RADIANT_LASER PDF leaflet English Size: (1.49 MB) |
PDF_LEAFLET_RADIANT_LASER_B04222_en.pdf |
| RADIANT_LASER PDF leaflet Français Size: (1.49 MB) |
PDF_LEAFLET_RADIANT_LASER_B04222_fr.pdf |
| RADIANT_LASER PDF leaflet Nederlands Size: (1.49 MB) |
PDF_LEAFLET_RADIANT_LASER_B04222_nl.pdf |
