Details
Details
- 2-way stereo or 3-way mono crossover
- Full scale frequency selection between 45 to 9600Hz
- 24dB/oct. Linkwitz - Riley filters
- All inputs and outputs are balanced or unbalanced with XLR connections
- Subsonic filter (40Hz) with ON/OFF switch
- Gain control on all inputs and outputs
- Phase inverter switch
- Stylish black design with blue and white LEDs
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 48.3 x 4.4 x 13.6 cm |
|---|---|
| General : Weight (kg) | 2.33 |
| General : Color | black |
| General : Powerinput | AC 240V, 50Hz |
| General : Energy Label | No |
| General : Display | none |
| General : Fixation | 19" rack mountable |
| General : RU | 1U |
| General : IP rating | indoor |
| Audio : min. frequency (Hz) | 20 |
| Audio : max. frequency (Hz) | 20000 |
| Audio : S/N ratio (> dB) | N/A |
| Audio : max. output channels | 2 |
| Audio : functions | equalizer, sound effects |
| Connections : input | 3 pin XLR, IEC |
| Connections : output | 3 pin XLR |
| Brand | JB SYSTEMS |
| EANCode | 5420025602877 |
Manual & Downloads
Manual & Downloads
 XO 2.4 Manual Size: (2.07 MB) |
XO 2.4 Manual |
| XO_2.4 PDF leaflet Nederlands Size: (377.81 KB) |
PDF_LEAFLET_XO_2.4_00287_nl.pdf |
| XO_2.4 PDF leaflet Deutsch Size: (378.41 KB) |
PDF_LEAFLET_XO_2.4_00287_de.pdf |
| XO_2.4 PDF leaflet English Size: (377.73 KB) |
PDF_LEAFLET_XO_2.4_00287_en.pdf |
| XO_2.4 PDF leaflet Français Size: (379.63 KB) |
PDF_LEAFLET_XO_2.4_00287_fr.pdf |
