Details
Details
- 2x 15-band stereo equalizer
- Balanced or unbalanced connections
- Level switch: +6 dB/+12 dB
- Equalizer bypass switch.
- Subsonic filter switch
- Standard 19” – 1Unit rack format.
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 48.2 x 4.45 x 16.5 cm |
|---|---|
| General : Weight (kg) | 2.7 |
| General : Color | black |
| General : Powerinput | AC 240V, 50Hz |
| General : Energy Label | No |
| General : Display | none |
| General : Fixation | 19" rack mountable |
| General : RU | 1U |
| General : IP rating | indoor |
| Audio : min. frequency (Hz) | 10 |
| Audio : max. frequency (Hz) | 20000 |
| Audio : max. output channels | 2 |
| Audio : functions | equalizer |
| Connections : input | 3 pin XLR, rca, jack, IEC |
| Connections : output | 3 pin XLR, rca, jack |
| Brand | JB SYSTEMS |
| EANCode | 5420025602884 |
Manual & Downloads
Manual & Downloads
 BEQ-15 Manual V1.1 Size: (1.1 MB) |
BEQ-15 User Manual V1.1 EN / FR / NL / DE / ES / PT |
| BEQ-15 EC Declaration Size: (454.49 KB) |
BEQ-15 EC Declaration of Conformity |
| BEQ-15 PDF leaflet Deutsch Size: (957.36 KB) |
PDF_LEAFLET_BEQ-15_B00288_de.pdf |
| BEQ-15 PDF leaflet English Size: (958.1 KB) |
PDF_LEAFLET_BEQ-15_B00288_en.pdf |
| BEQ-15 PDF leaflet Français Size: (958.3 KB) |
PDF_LEAFLET_BEQ-15_B00288_fr.pdf |
| BEQ-15 PDF leaflet Nederlands Size: (957.53 KB) |
PDF_LEAFLET_BEQ-15_B00288_nl.pdf |
