- A very powerful, eye-catching, LED effect.
- Based on 7 LED clusters with 392 power LEDs(R=140 + G=105 + B=84 + W=63):
- Extremely brilliant colors compared to effects with halogen lamps
- More dynamic effects compared to effects based on halogen lamps
- Very sharp white, blue, red and green laser-like beams
- No lamp replacements!
- Uses LEDs with extremely long lifespan!
- Virtually no heat production
- Very low power consumption
- Lightweight (no lamp transformers needed)
- 0-100% dimming and ultra fast strobe function
- Excellent built-in programs for wonderful, ever changing, light shows:
- DMX-control: selectable 4 or 10 channelsfor full control of the 7 LED clusters
- Standalone: sound activated with internal mic
- Master/slave: wonderful synchronized shows
- Optional CA-8 remote controller available
- 4-digit menu driven display
- Equipped with big optical lens for maximum light output and wide 54° beam angle
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 30 x 30.8 x 28 cm |
|---|---|
| General : Weight (kg) | 5.53 |
| General : Powerinput | AC 240V, 50Hz |
| General : Works on battery | N/A |
| General : Energy Label | No |
| General : Power consumption W | 50 |
| General : Color | black |
| General : Display | none |
| General : Fixation | optional standard clamp |
| General : IP rating | indoor |
| Control : Modes | N/A |
| Control : Protocol | N/A |
| Control : optional remote | CA-8 |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | N/A |
| Light : lamp socket | none |
| Light : lamp | LED |
| Light : colors | Red, Green, Blue, White |
| Light : mix colors | No |
| Light : functions | N/A |
| Light : min. beam angle (°) | 54 |
| Light : max. beam angle (°) | 54 |
| Light : max. refresh rate (kHz) | No |
| Connections : output | N/A |
| Brand | JB SYSTEMS |
| EANCode | 5420025641364 |
Manual & Downloads
Manual & Downloads
 CYCLOPE Manual Size: (2.7 MB) |
CYCLOPE Manual |
 CYCLOPE Chromateq fixture files Size: (1.06 KB) |
CYCLOPE Chromateq fixture files |
