- A powerful logo projector based on a 50W cold white led.
- Low gobo temperature: no need for expensive heat resistant metal or glass gobos!
- Four FREE metal gobos included: [Sale, Happy New-Year, Presents, Hearts]
- Uses standard metal gobos and glass gobos.
- Can also be used with plastic film gobos that can be produced by a standard laser printer!
(Gobo templates and instructions available on our website) - Adjustable beam angle: 20° to 34°
- Adjustable focus.
- Different working modes:
- Standalone: Manual settings for dimmer, strobe and rotation (with IR-remote).
- Master/slave mode: several projectors can be used together for synchronized projections.
- DMX-controlled: 1, 2, 3 or 4 channel mode.
- Infrared remote control included.
- Prepared for wireless DMX: just plug-in an optional WTR-DMX DONGLE !
- 2x 8 alphanumeric LED-display for easy menu navigation.
- Very low noise operation: can be used in shops and showrooms.
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 50 x 15 x 10 |
|---|---|
| General : Weight (kg) | 2.77 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Energy Label | No |
| General : Power consumption W | 56 |
| General : Color | black |
| General : Display | LCD |
| General : IP rating | indoor |
| Control : Modes | standalone fixed, standalone automatic, remote, manual, DMX, Master/Slave |
| Control : Protocol | DMX, Wireless DMX |
| Control : Type included remote | Wireless IR remote |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | 1 |
| Control : maximum DMX channels | 4 |
| Light : lamp socket | No |
| Light : lamp | LED |
| Light : colors | Cold white |
| Light : mix colors | No |
| Light : functions | manual focus, manual zoom |
| Light : min. beam angle (°) | 20 |
| Light : max. beam angle (°) | 34 |
| Light : max. refresh rate (kHz) | No |
| Connections : input | 3 pin XLR, wireless DMX optional, PowerCon® or compatible |
| Connections : output | 3 pin XLR, PowerCon® or compatible |
| Brand | JB SYSTEMS |
| EANCode | 5420025651660 |
Manual & Downloads
Manual & Downloads
 ROTOGOBO ZOOM - Gobo template Size: (6.61 MB) |
ROTOGOBO ZOOM - Gobo template |
 ROTOGOBO ZOOM - Manual EN Size: (1.08 MB) |
ROTOGOBO ZOOM - Operation Manual English |
| ROTOGOBO ZOOM - Manual FR Size: (1.03 MB) |
ROTOGOBO ZOOM - Mode d'emploi Français |
| ROTOGOBO ZOOM - Manual NL Size: (1008.1 KB) |
ROTOGOBO ZOOM - Handleiding Nederlands |
| ROTOGOBO ZOOM - Manual DE Size: (1017.52 KB) |
ROTOGOBO ZOOM - Bedienungsanleitung Deutsch |
| ROTOGOBO ZOOM - Manual ES Size: (1008.02 KB) |
ROTOGOBO ZOOM - Manual de instrucciones Español |
| ROTOGOBO ZOOM - EC Declaration Size: (456.53 KB) |
ROTOGOBO ZOOM - EC Declaration of Conformity |
| ROTOGOBO_ZOOM PDF leaflet Deutsch Size: (1.04 MB) |
PDF_LEAFLET_ROTOGOBO_ZOOM_B05166_de.pdf |
| ROTOGOBO_ZOOM PDF leaflet English Size: (1.03 MB) |
PDF_LEAFLET_ROTOGOBO_ZOOM_B05166_en.pdf |
| ROTOGOBO_ZOOM PDF leaflet Français Size: (1.04 MB) |
PDF_LEAFLET_ROTOGOBO_ZOOM_B05166_fr.pdf |
| ROTOGOBO_ZOOM PDF leaflet Nederlands Size: (1.03 MB) |
PDF_LEAFLET_ROTOGOBO_ZOOM_B05166_nl.pdf |
