Details
Details
- An extremely compact but very bright Moving Head, based on a 120W LED
- The perfect solution for many applications: DJ’s, parties, pubs, small clubs,...
- Motorized focus, controlled by DMX
- Manual zoom: 12° to 17°
- 3 facet rotating prism
- 0-100% dimming and different strobe effects
- Gobo wheel with 6 rotating gobos + open
- Color wheel with 8 colors, split colors + open
- Excellent built-in programs for wonderful, ever changing, light shows.
- Multiple working modes:
- DMX-control: using 5, 15 or 18 channels
- Standalone: sound activated with internal mic
- Master/slave: wonderful synchronized shows in standalone mode
- Prepared for wireless DMX: just plug-in an optional WTR-DMX DONGLE !
- Color LCD-display with 4 touch buttons for easy menu navigation
- PowerCON compatible input
- 3p XLR connectors for DMX in- and output
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 23.5 x 16.6 x 37.4(H) |
|---|---|
| General : Weight (kg) | 7.7 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Energy Label | No |
| General : Power consumption W | 150 |
| General : Color | black |
| General : Display | LCD |
| General : Fixation | included omega bracket |
| General : IP rating | indoor |
| Control : Modes | standalone sound, DMX, Master/Slave |
| Control : Protocol | DMX, Wireless DMX |
| Control : programmable | No |
| Control : upgradable software | Yes |
| Control : minimum DMX channels | 5 |
| Control : maximum DMX channels | 18 |
| Light : lamp socket | No |
| Light : Lux | 1130 @5m (beam 13°) |
| Light : lamp | LED |
| Light : mix colors | No |
| Light : functions | motorized focus, manual zoom, 3 facet round prism |
| Light : rotating gobos | 6 |
| Light : min. beam angle (°) | 11 |
| Light : max. beam angle (°) | 17 |
| Light : max. refresh rate (kHz) | No |
| Connections : input | 3 pin XLR, wireless DMX optional, PowerCon® or compatible |
| Connections : output | 3 pin XLR |
| Brand | JB SYSTEMS |
| EANCode | 5420025655439 |
Manual & Downloads
Manual & Downloads
 EXPLORER SPOT - Manual EN Size: (1.76 MB) |
EXPLORER SPOT - User Manual English |
| EXPLORER SPOT - Manual FR Size: (1.47 MB) |
EXPLORER SPOT - Mode d'emploi Français |
| EXPLORER SPOT - Manual NL Size: (1.72 MB) |
EXPLORER SPOT - Handleiding Nederlands |
| EXPLORER SPOT - Manual DE Size: (1.72 MB) |
EXPLORER SPOT - Bedienungsanleitung Deutsch |
| EXPLORER SPOT - Manual ES Size: (1.73 MB) |
EXPLORER SPOT - Manual de instrucciones Español |
| EXPLORER SPOT - EC Declaration Size: (445.02 KB) |
EXPLORER SPOT - EC Declaration of Conformity |
 EXPLORER SPOT - Firmware V1.0 Size: (249.09 KB) |
EXPLORER SPOT - Firmware V1.0 (2023-12-07) |
| EXPLORER_SPOT PDF leaflet Deutsch Size: (1.41 MB) |
PDF_LEAFLET_EXPLORER_SPOT_B05543_de.pdf |
| EXPLORER_SPOT PDF leaflet English Size: (1.41 MB) |
PDF_LEAFLET_EXPLORER_SPOT_B05543_en.pdf |
| EXPLORER_SPOT PDF leaflet Français Size: (1.4 MB) |
PDF_LEAFLET_EXPLORER_SPOT_B05543_fr.pdf |
| EXPLORER_SPOT PDF leaflet Nederlands Size: (1.4 MB) |
PDF_LEAFLET_EXPLORER_SPOT_B05543_nl.pdf |
