Details
Details
- Thiele & Small parameters: see downloads
- Impedance: 8 ohm
- Power: 200 Wrms
- Freq.Response: 85-4500Hz
- Sensitivity (1W/1m): 93dB
- Application: Bass / Mid
- Hole cutout: 230mm
- Basket material: steel
- Net weight: 2,92kg
Technische gegevens
Technische gegevens
| Algemeen : Afmetingen (cm) | dia 25.6 cm |
|---|---|
| Algemeen : Gewicht (kg) | 4 |
| Audio : min. frequentie (Hz) | 85 |
| Audio : max. frequentie (Hz) | 4500 |
| Audio : Wrms 8Ω stereo, per kanaal | 200 |
| Merk | JB SYSTEMS |
| EANCode | 5420025606790 |
Handleiding & Downloads
Handleiding & Downloads
 PWX 10/200 Small / Thiele parameters Size: (74.12 KB) |
PWX 10/200 Small / Thiele parameters |
