Details
Details
- Multi-purpose PA mixer in a handy 19” Rack format.
- 10 inputs on 7 channels (4 mic/line, 2 mic/stereo line, 1 player/stereo in/usb).
- The USB connector is Bidirectional (for mono recording or stereo playback via PC/Mac).
- Internal WMA, WAV, FLAC, APE and MP3 media player for USB memory sticks.
- The media player can also be used as a mono mp3 recorder (128kbps).
- Integrated Bluetooth receiver.
- Internal 32bit DSP-effect unit with 16 effects + separate parameter control
- Input control on all the channels:
- Gain (not on input 9-10/media player)
- Pan
- Low Cut switch (not on input 9-10/media player)
- Treble, mid, bass (Treble, bass on input 9-10/media player)
- Aux send (Post Fader)
- Effect send
- Channel level
- PFL button (not on input 9-10/media player)
- General 48V Phantom Power switch.
- 1 Master + 1 Group output with individual level control.
- Aux Send output + Return input with individual level control.
- Headphones + control room outputs with level control.
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 48(W) x 20(D) x 15(H) |
|---|---|
| General : Weight (kg) | 4.14 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Energy Label | No |
| General : Power consumption W | 25 |
| General : Color | black |
| General : Display | No |
| General : Fixation | 19" rack mountable |
| General : RU | No |
| Audio : min. frequency (Hz) | 20 |
| Audio : max. frequency (Hz) | 20000 |
| Audio : supported audio formats | APE, FLAC, MP3, WAV, WMA |
| Audio : supported audio media | USB |
| Audio : functions | equalizer, sound effects |
| Connections : input | 3 pin XLR, rca, jack, usb, bluetooth |
| Connections : output | 3 pin XLR, rca, jack |
| Brand | JB SYSTEMS |
| EANCode | 5420025684057 |
Manual & Downloads
Manual & Downloads
 LIVERACK-10 - Manual EN Size: (4.01 MB) |
LIVERACK-10 - User Manual English |
| LIVERACK-10 - Manual FR Size: (3.9 MB) |
LIVERACK-10 - Mode d'emploi Français |
| LIVERACK-10 - Manual NL Size: (3.89 MB) |
LIVERACK-10 - Handleiding Nederlands |
| LIVERACK-10 - Manual DE Size: (3.89 MB) |
LIVERACK-10 - Bedienungsanleitung Deutsch |
| LIVERACK-10 - Manual ES Size: (3.9 MB) |
LIVERACK-10 - Manual de instrucciones |
| LIVERACK-10 - EC Declaration Size: (451.63 KB) |
LIVERACK-10 - EC Declaration of Conformity |
| LIVERACK-10 PDF leaflet Deutsch Size: (1.18 MB) |
PDF_LEAFLET_LIVERACK-10_B08405_de.pdf |
| LIVERACK-10 PDF leaflet English Size: (1.18 MB) |
PDF_LEAFLET_LIVERACK-10_B08405_en.pdf |
| LIVERACK-10 PDF leaflet Français Size: (1.18 MB) |
PDF_LEAFLET_LIVERACK-10_B08405_fr.pdf |
| LIVERACK-10 PDF leaflet Nederlands Size: (1.18 MB) |
PDF_LEAFLET_LIVERACK-10_B08405_nl.pdf |
